Replacement Ignition Coil 96453420 UF698
IGNX No: STIC2206
OE No.:
96453420
SMP :
Inquiry Now >>
UF-698 (UF698)
Product Detail
| ST NO. | Brand | OEM No. | Model(s) & Years | PINS | MODULE |
| STIC2206 | CHEVROLET | 96453420 | CHEVROLET NUBIRA 1.4L / 1.6L (2005-2011) CHEVROLET OPTRA 1.6L (2003-2008) CHEVROLET LACETTI 1.6L (2005-2010) CHEVROLET CRUZE 1.6L (2009) |
4 PINS | WITHOUT |
| DAEWOO | 96453420 | DAEWOO NUBIRA 1.6L (1997-2003) DAEWOO LACETTI 1.4L / 1.6L (2004-/) DAEWOO NEXIA 1.6L (2008-/) |
4 PINS | WITHOUT |
This Chevrolet / Daewoo ignition coil is supplied for the listed OE number 96453420. It uses a 4 pins connector and without-module configuration, so the electrical interface, housing profile, mounting arrangement, and overall coil structure are important points to review when confirming a replacement product.
During product comparison, buyers can check the OE number together with connector orientation, terminal position, plug direction, housing shape, mounting details, and overall dimensions of the original coil. Reviewing several physical characteristics together provides a clearer basis for product confirmation than relying only on the part number or exterior appearance.
Product Matching and Interface Check
Listed OE Number
Check 96453420 against the original component during sample review, catalog preparation, quotation, or order confirmation. The OE reference can be considered together with the physical coil structure.
4 Pins Connector
The 4 pins connector is a key visible matching feature. Connector shape, terminal arrangement, locking position, plug direction, and installation orientation can be compared with the original ignition coil.
Without Module Structure
This ignition coil is listed as without module. Module status can be reviewed together with connector layout, housing design, and mounting structure when confirming the required replacement configuration.
Electrical Construction and Inspection Focus
Ignition coil operation is related to the condition of the primary and secondary windings, internal insulation, terminals, and electrical connections. During product evaluation, these areas can be reviewed together with connector fit, housing condition, mounting dimensions, and general assembly condition.
Engine heat, temperature changes, vibration, and repeated electrical loading are common operating conditions around ignition components. Depending on the buyer's inspection requirements, checking may include terminal contact, connector condition, housing integrity, insulation-related characteristics, and relevant electrical measurements.
Sample and Batch Specification Review
During sample evaluation, the replacement coil can be compared with the original part for the listed OE number, 4 pins connector, without-module structure, connector orientation, housing profile, and mounting details. Original coil photos or connector close-ups can provide additional reference when further visual confirmation is required.
For repeat or batch purchasing, the approved sample can be retained as a reference for product structure, connector configuration, visible assembly details, labeling, and packaging requirements. Any project-specific specifications can then be reviewed before subsequent order arrangements.
