Ignition Coil 24531916/23872290 UF853
IGNX No: STIC4103
OE No.:
24531916
23872290
F01R00A027
SMP :
Inquiry Now >>
UF-853 (UF853)
Product Detail
| ST NO. | Brand | OEM No. | Model(s) & Years | PINS | MODULE |
| STIC4103 | CHEVROLET | 24531916 23872290 F01R00A027 |
CHEVROLET N200 N300 N300P | 3 PINS | WITHOUT |
This Chevrolet ignition coil is supplied for the listed OE numbers 24531916, 23872290, and F01R00A027. It uses a 3 pins connector and without-module configuration, so connector layout, housing profile, mounting arrangement, and overall coil structure are useful points to review when confirming the required replacement product.
During product comparison, buyers can check the applicable OE number together with connector orientation, terminal position, plug direction, housing shape, mounting details, and overall dimensions of the original coil. Reviewing several structural details together provides a clearer basis for confirmation than relying only on the part number or exterior appearance.
Connector and Housing Confirmation
Listed OE References
Confirm the applicable listed OE number against the original component during sample review, quotation, catalog preparation, or order confirmation. OE information should be considered together with the physical coil design.
3 Pins Connector
The 3 pins connector is an important visible matching point. Connector shape, terminal layout, locking position, plug direction, and installation orientation can be compared directly with the original ignition coil.
Without Module Structure
This ignition coil is listed as without module. Module status can be checked together with connector configuration, housing shape, and mounting structure when confirming the required product version.
Electrical and Insulation Inspection Focus
Ignition coil condition is related to the primary and secondary windings, internal insulation, terminals, and electrical connections. During product evaluation, these areas can be reviewed together with connector fit, housing condition, mounting dimensions, and general assembly condition.
Engine heat, repeated temperature changes, vibration, and electrical loading are common conditions around ignition components. Depending on the inspection requirements, checking may include terminal contact, connector condition, housing integrity, insulation-related characteristics, and relevant electrical measurements.
Sample and Supply Specification Review
During sample evaluation, the supplied coil can be compared with the original part for the applicable OE number, 3 pins connector, without-module structure, connector orientation, housing profile, and mounting details. Original-part photos or connector close-ups can also provide additional visual reference when further confirmation is required.
Once the product structure has been confirmed, the approved sample can serve as a reference for subsequent purchasing communication. Connector configuration, visible assembly details, labeling, packaging, order quantity, and other project-specific requirements can then be reviewed according to the purchasing plan.
