Ignition Coil 3L3Z12029BA/3L3E12A366CA FD508
IGNX No: STIC4018
OE No.:
3L3Z12029BA
3L3E12A366CA
3L3U12A366BB
SMP :
Inquiry Now >>
FD-508 (FD508)
Product Detail
| ST NO. | Brand | OEM No. | Model(s) & Years | PINS | MODULE |
| STIC4018 | FORD | 3L3Z12029BA 3L3E12A366CA 3L3U12A366BB |
FORD MUSTANG 4.6L V8 (2004-/) FORD F-250 5.4L V8 (2003-2007) FORD F-350 5.4L V8 (2003-2007) FORD EXPLORER 4.6L V8 (2006-/) |
2 PINS | WITHOUT |
This Ford ignition coil is supplied for the listed OE numbers 3L3Z12029BA, 3L3E12A366CA, and 3L3U12A366BB. It uses a 2 pins connector and without-module configuration, so connector design, housing profile, mounting position, and overall coil structure are useful reference points when reviewing a replacement product.
During product comparison, buyers can review the applicable OE number together with connector orientation, terminal position, plug direction, mounting details, and overall dimensions of the original coil. Checking several structural points together provides a clearer reference than relying only on exterior appearance.
Structure and Matching Details to Review
Listed OE Numbers
Check the applicable listed OE number against the original part during sample review, quotation, catalog preparation, or order confirmation. The OE reference can be reviewed together with the physical coil structure.
2 Pins Connector
The 2 pins connector is an important matching feature. Connector shape, terminal arrangement, locking position, plug direction, and installation orientation can be compared with the original ignition coil.
Without Module Configuration
This ignition coil is listed as without module. Module status can be considered together with the connector, housing design, and mounting arrangement when confirming the required replacement structure.
Winding, Insulation and Electrical Condition
Ignition coil operation is related to the primary and secondary windings, internal insulation, terminals, and electrical connections. During product evaluation, these areas can be considered together with connector fit, housing condition, mounting dimensions, and general assembly condition.
Engine heat, temperature changes, vibration, and repeated electrical loading are common operating conditions around ignition components. Depending on the buyer's inspection requirements, evaluation may include connector and terminal condition, housing condition, insulation-related characteristics, and relevant electrical measurements.
Sample and Order Specification Review
During sample evaluation, the replacement coil can be compared with the original part for the listed OE number, 2 pins connector, without-module structure, connector orientation, housing profile, and mounting details. Original coil photos or connector close-ups can provide additional reference when further comparison is required.
For regular purchasing, the reviewed sample and confirmed product structure can serve as a reference for later order communication. Packaging method, label information, required quantity, and other project-specific details can be reviewed according to the buyer's purchasing requirements.
