Ignition Coil CM5Z12029B/CM5Z12029C UF736
IGNX No: STIC4033
OE No.:
CM5Z12029B
CM5Z12029C
CM5G12366CA
SMP :
Inquiry Now >>
UF-736 (UF736)
Product Detail
| ST NO. | Brand | OEM No. | Model(s) & Years | PINS | MODULE |
| STIC4033 | FORD | CM5Z12029B CM5Z12029C CM5G12366CA |
FORD FIESTA 1.0L (2014) | 3 PINS | WITH |
This Ford ignition coil is supplied for the listed OE numbers CM5Z12029B, CM5Z12029C, and CM5G12366CA. It features a 3 pins connector and with-module configuration, so connector layout, module structure, housing design, and mounting details are useful points to review when selecting a replacement coil.
During product comparison, buyers can check the listed OE number together with connector orientation, terminal position, plug direction, housing profile, mounting arrangement, and overall dimensions of the original part. Reviewing several structural details together provides more reference than identifying the coil only by exterior appearance.
Connector and Module Details to Review
Listed OE Numbers
Check the applicable listed OE number against the original part during sample review, quotation, catalog preparation, or order confirmation. The OE reference can be considered together with the physical coil structure.
3 Pins Connector
The 3 pins connector is an important matching feature. Connector shape, terminal arrangement, locking position, plug direction, and installation orientation can be compared with the original ignition coil.
With Module Configuration
This ignition coil is listed as with module. Module configuration can be reviewed together with connector and housing details when confirming the required replacement structure.
Electrical Construction and Inspection Focus
Ignition coil operation is related to the primary and secondary windings, internal insulation, terminals, electrical connections, and control-related components within the coil assembly. During product evaluation, these areas can be considered together with connector fit, housing condition, mounting dimensions, and general assembly condition.
Engine heat, temperature changes, vibration, and repeated electrical loading are common operating conditions around ignition components. Depending on the buyer's inspection requirements, evaluation may include connector and terminal condition, housing condition, insulation-related characteristics, and relevant electrical measurements.
Sample and Order Specification Review
During sample evaluation, the replacement coil can be compared with the original part for the listed OE number, 3 pins connector, with-module structure, connector orientation, housing profile, and mounting details. Original coil photos or connector close-ups can also provide additional reference when further comparison is required.
For regular purchasing, the reviewed sample and confirmed product structure can serve as reference for later order communication. Packaging method, label information, required quantity, and other project-specific details can be reviewed according to the buyer's purchasing requirements.
