Ignition Coil 1404981/1716750 UF516
IGNX No: STIC4041
OE No.:
1404981
1716750
6E5Z12029AA
6E5G12A366AD
6E5G12A366AE
SMP :
Inquiry Now >>
UF-516 (UF516)
Product Detail
| ST NO. | Brand | OEM No. | Model(s) & Years | PINS | MODULE |
| STIC4041 | FORD | 1404981 1716750 6E5Z12029AA 6E5G12A366AD 6E5G12A366AE |
FORD GALAXY 2.3L (2007-2015) FORD S-MAX 2.3L (2007-/) FORD MONDEO 2.3L (2007-2015) |
2 PINS | WITHOUT |
This Ford ignition coil is supplied for the listed OE numbers 1404981, 1716750, 6E5Z12029AA, 6E5G12A366AD, and 6E5G12A366AE. It uses a 2 pins connector and without-module configuration, so connector layout, housing structure, mounting position, and overall coil design are useful points to review when selecting a replacement product.
During product comparison, buyers can review the applicable OE number together with connector orientation, terminal position, plug direction, housing profile, mounting arrangement, and overall dimensions of the original coil. Checking several structural details together provides more reference than identifying the product by exterior appearance alone.
Key Structure Details to Review
Listed OE Numbers
Check the applicable listed OE number against the original part during sample review, quotation, catalog preparation, or order confirmation. The OE reference can be considered together with the physical coil structure.
2 Pins Connector
The 2 pins connector is an important matching feature. Connector shape, terminal arrangement, locking position, plug direction, and installation orientation can be compared with the original ignition coil.
Without Module Configuration
This ignition coil is listed as without module. Module status can be reviewed together with the connector, housing design, and mounting arrangement when confirming the required replacement structure.
Electrical Construction and Condition Checks
Ignition coil operation is related to the condition of the primary and secondary windings, internal insulation, terminals, and electrical connections. During product evaluation, these areas can be considered together with connector fit, housing condition, mounting dimensions, and general assembly condition.
Engine heat, temperature changes, vibration, and repeated electrical loading are common operating conditions around ignition components. Depending on the buyer's inspection requirements, evaluation may include terminal contact, connector condition, housing condition, insulation-related characteristics, and relevant electrical measurements.
Sample and Product Specification Review
During sample evaluation, the replacement coil can be compared with the original part for the listed OE number, 2 pins connector, without-module structure, connector orientation, housing profile, and mounting details. Original coil photos or connector close-ups can also provide additional reference when further comparison is required.
For regular purchasing, the reviewed sample and confirmed product structure can be used as reference for later order communication. Packaging method, label information, required quantity, and other project-specific details can be discussed according to the buyer's purchasing requirements.
